General |
|
| Dimension | 13.54" x 6.1" x 1.97" (344 x 155 x 50 mm) |
|---|---|
| Weight |
2.54 lbs (1.15 kg) |
|
Water rating |
IP65 (when properly installed) |
| Operating temperature | 32° to 122° F (0° to 50° C) |
| Current (max) | 10 A |
Networking |
|
| Bluetooth® wireless range | up to 30 ft |
|---|---|
| ANT® wireless range | Up to 10 ft |
| Wireless frequencies/protocols | BLUETOOTH®: 2.4 GHz @ +9 dBm nominal ANT®: 2.4 GHz @ +9 dBm nominal |
Audio |
|
| Amplifier | Class-D |
|---|
Electrical Features |
|
| Power Input | 10.8 – 16 VDC |
|---|---|
| Compass-safe distance | 7.6" (229 mm) |
Stereo Features |
|
| Peak power | 140 watts |
|---|---|
| Rated power output (2 ohm) | 43 watts RMS x 2 @ 14.4 V input < 1% THD |
| Built-in Digital Signal Processing (DSP) | yes (preconfigured) |
| Fusion-Link™ control | yes (smart device and Garmin watch) |
| Bluetooth® wireless technology | |
| ANT® wireless technology | |
| Multi-language interface |
Chinese (Mandarin), Dutch, English, French, German, Italian, Japanese, Spanish |
| Software updates | USB |
| Warranty | 1year |
Sources |
|
| Supported sources |
AM, FM, BLUETOOTH®, USB audio, iPhone®, iPod®, AUX x2, AOA |
|---|
Connections |
|
| Auxiliary inputs (RCA) | 2 |
|---|---|
| USB 2.0 ports | 1 |
| AM/FM ports (Motorola antenna connector) | 1 |
| Line out | 1 RCA Output (AUX) |
