General |
|
| Physical dimensions (Height) | MM105: 3.91" (99 mm) MM105-HR: 2.32" (59 mm) |
|---|---|
| Physical dimensions (Width) | MM105: 5.95" (151 mm) MM105-HR: 7.70" (196 mm) |
| Physical dimensions (Depth) | MM105: 3.94" (100 mm) MM105-HR: 6.69" (170 mm) with harness bend |
| Control Surface Dust/Water Rating (when properly installed) | MM105: IP67 MM105-HR: IP66 |
| Operating temperature range | -4° F to +158° F (-20° C to +70° C) |
| Current draw (max) | 1.5 A |
| Warranty | 3 years |
Networking |
|
| NMEA 2000® LEN | 1 (50 mA) |
|---|---|
| Bluetooth® wireless range | Up to 35 ft (11 meters) |
| Wireless frequencies/protocols | BLUETOOTH® |
Electrical Features |
|
| Power Input | 10-15.9 VDC |
|---|
Stereo Features |
|
| Display size | MM105: 3.5" (89 mm) |
|---|---|
| Display type | MM105: color TFT LCD, backlit |
| Display resolution | MM105: 320 x 480 |
| Multi-Zone™ technology | |
| Bluetooth® wireless technology | |
| SiriusXM-ready | |
| DAB+ ready | |
| Multi-language interface | MM105: English/French/German/Italian/Spanish |
| Software updates | USB |
Sources |
|
| Supported sources | AM/FM with RDS Digital HD Radio (North America only) DAB+ (Europe only)/BLUETOOTH®/USB audio/iPhone®/iPod®/AUX x2/SiriusXM-Ready (US & Canada only, requires subscription and SiriusXM Connect vehicle tuner) |
|---|---|
| Supported audio formats (USB) | MP3, MP4, WAV (up to 1411 kbps), AAC, M4A, M4B |
Connections |
|
| Auxiliary inputs (RCA) | 2 (2V or 1V RMS Input Sensitivity) |
|---|---|
| NMEA 2000® ports | 1 (Micro-C connector) |
| USB 2.0 ports | 2 USB1: High-speed connection for use with iPhone®/iPod® (Mfi-certified) or USB storage device (1 A charging output) USB2: Full-speed USB storage device connection (500 mA charging output) |
| SiriusXM ports | 1 |
| AM/FM ports (Motorola antenna connector) | 1 |
| RCA pre-out (left, right and subwoofer – requires external amplification) | 4 zones |
| Line out (requires external amplification) | 4 (L + R per zone) |
| Subwoofer out (requires external amplification) | 4 (1 mono output per zone) |
