General |
|
| Sizes | 10"/10" Truck/12"/12" Truck |
|---|---|
| Physical dimensions (Height) | 10": 14" (357 mm) 10" Truck: 12.375" (314 mm) 12": 15.625" (397 mm) 12" Truck: 14.625" (371 mm) |
| Physical dimensions (Width) | 10": 20.75" (527 mm) 10" Truck: 19" (483 mm) 12": 23.75" (603 mm) 12" Truck: 12": 21.75" (537 mm) |
| Physical dimensions (Depth) | 10": 4.5" (114 mm) 10" Truck: Top: 4.1" (104 mm) 10" Truck: Base: 6.25" (159 mm) 12": 5.0625" (129 mm) 12" Truck: Top: 4.5" (114 mm) 12" Truck: Base: 7" (178 mm) |
| Weight | 10"/10" Truck: 21.2 lbs (9.6 kg) 12": 30.5 lbs (13.8 kg) 12" Truck: 29 lbs (13.2 kg) |
| Continuous power handling (RMS) | 400 W |
| Nominal impedance | 2 Ω |
| Recommended amplifier power (RMS) | 100-400 W |
| Cone material | Mineral-filled polypropylene |
| Enclosure type | 10"/12": Sealed 10" Truck/12" Truck: Sealed, truck enclosure |
| Grille(s) included | |
| Warranty | 2 years |
Connections |
|
| Speaker connections | Five-way binding post terminal |
|---|
