General |
|
| Physical dimensions (Height) | Controller: 2.15" (55 mm) Receiver: 2.28" (58 mm) |
|---|---|
| Physical dimensions (Width) | Controller: 2.15" (55 mm) Receiver: 2.64" (67 mm) |
| Physical dimensions (Depth) | Controller: 3.10" (79 mm) Receiver: 0.79" (20 mm) |
| Control Surface Dust/Water Rating (when properly installed) | Controller: IP67 Receiver: IPX7 |
| Current draw (max) | Controller: 108 mA Receiver: 40 mA |
| Warranty | 2 years |
Networking |
|
| Bluetooth® wireless range | Up to 35 ft (11 meters) |
|---|---|
| Wireless frequencies/protocols | Bluetooth® |
Electrical Features |
|
| Power Input | Controller: 8-16 VDC Receiver: 10-16 VDC |
|---|
Stereo Features |
|
| Multi-Zone™ technology | see Additional |
|---|---|
| Bluetooth® wireless technology |
Sources |
|
| Supported sources |
Bluetooth® |
|---|
Connections |
|
| RCA pre-out (left, right and subwoofer – requires external amplification) | Controller: 2 zones (L+R), 1 mono output Receiver: L + R only |
|---|---|
| Line out (requires external amplification) | Controller: 2 (L + R per zone) Receiver: 1 (L + R) |
| Subwoofer out (requires external amplification) | Controller: Zone 1 (1 mono output) |
Additional |
|
| Additional | Multi-Zone Technology: Controller only |
|---|
