General |
|
| Physical dimensions (Height) | MMR-40: 3.74" (95 mm) |
|---|---|
| Physical dimensions (Width) | MMR-40: 4.65" (118 mm) |
| Physical dimensions (Depth) | MMR-40: 3.67" (93 mm) |
| Control Surface Dust/Water Rating (when properly installed) | IP66 |
| Operating temperature range | -4° F to +158° F (-20° C to +70° C) |
| Warranty | 3 years |
Networking |
|
| NMEA 2000® LEN | 4 (200 mA) |
|---|
Stereo Features |
|
| Display size | MMR-40: 2.8" (71 mm) |
|---|---|
| Display type | MMR-40: color TFT LCD, backlit |
| Display resolution | MMR-40: 320 x 240 |
| Multi-language interface |
English |
| Software updates | USB |
Sources |
|
| Supported sources |
Derived from host source unit |
|---|---|
| Supported audio formats (USB) | Derived from host source unit |
Connections |
|
| NMEA 2000® ports | 1 (Micro-C connector) |
|---|---|
| USB 2.0 ports | 1 (Software update only) |
