General |
|
| Transducer beamwidth | With lens: 12° x 120° Without lens: 57° x 120° |
|---|---|
| Transducer cable length | 9.8′ (3 m) |
| Dimension | 9.1” x 4.1” x 2.5” (23.1 x 10.4 x 6.4 cm) |
| Weight |
2.60 lbs (1.18 kg) |
| Temperature range | Operating: 0° C to 40° C |
Electrical Features |
|
| Power input | 10-32 V |
|---|---|
| Fuse | 4A |
Sonar Features |
|
| Frequency | 417 kHz |
|---|---|
| Transmit power | 48 W |
| Maximum depth | 300′ |
Connections |
|
| Garmin Marine Network Ports |
1 (standard connector) |
|---|
Sonar Modes |
|
| LiveVü Down | |
|---|---|
| LiveVü Forward | |
| Traditional sonar source |
