General |
|
| Transducer beamwidth | 120° x 20° |
|---|---|
| Transducer cable length | 6 ft, power; 6 ft + 50 ft ext., Ethernet |
| Dimension | 1.58" x 7.58" (40 x 192.5 mm) |
| Weight |
1.8 lbs (800 g) |
| Temperature range | 0° C to 50° C |
Electrical Features |
|
| Power input | 10-35 V |
|---|---|
| Power usage | 9 W |
| Fuse | 4.0 A |
Sonar Features |
|
| Frequency | 417 kHz |
|---|---|
| Transmit power | 96 W |
| Maximum depth | 300′ (forward range is typically 8x depth) |
| Sonar Type | Multi-beam phased array |
Connections |
|
| Garmin Marine Network Ports |
1 (large RJ45) |
|---|
Sonar Modes |
|
| LiveVü Forward | |
|---|---|
| FrontVü |
