General |
|
| Transducer beamwidth | 120° x 8° |
|---|---|
| Transducer cable length | 8 ft + 40 ft extension |
| Dimension | 8.50" x 4.49" x 9.61" (21.6 x 11.4 x 24.4 cm) |
| Weight |
10.12 lbs (4.6 kg) |
|
Water rating |
IPX7 |
| Temperature range | 0° C to 40° C |
Electrical Features |
|
| Power input | 10-35 V |
|---|---|
| Power usage | 35 W |
| Fuse | 7.5 A |
Sonar Features |
|
| Frequency | 190-210 kHz |
|---|---|
| Transmit power | 800 W |
| Maximum depth | Saltwater: 1000′ (304.8 m) |
| Sonar Type | Multi-beam phased array |
Connections |
|
| Garmin Marine Network Ports |
1 (small connector) |
|---|
Sonar Modes |
|
| RealVü 3D Historic | |
|---|---|
| 3-beam traditional | |
| Traditional sonar source |
