General |
|
| Dimension | 3” x 2.97” x 2.28” (75.8 x 75.5 x 57.87 mm) |
|---|---|
| Weight |
2.6 oz (75 g) |
|
Water rating |
IPX7 |
| Battery life |
10 hours |
Maps & Memory |
|
| Waypoints/favorites/locations | 5000 |
|---|
Sensors |
|
| GPS | |
|---|---|
| Has built-in receiver | |
| Receiver | 260/455 kHz |
| Supports WAAS |
Optional Map Support |
|
| Garmin Quickdraw Contours |
|---|
Sonar Features |
|
| Displays sonar | |
|---|---|
| Traditional sonar (dual frequency/beam) | |
| Frequency | 260/455 kHz |
| Transmit power | 7.78 dBm maximum |
| Bottom Lock (shows return from the bottom up) | |
| Water Temperature Log |
Connections |
|
| Bluetooth® pairing |
|---|
Fishfinder Features |
|
| Fish Symbol ID (helps identify fish targets) | |
|---|---|
| Autogain technology (minimizes clutter; maximizes targets) | |
| Adjustable depth line (measures depth of underwater objects) | |
| A-scope (real time display of fish passing through transducer beam) | |
| Water temperature sensor included | |
| Depth range shading |
Castable Fishfinder Features |
|
| Included teather length | 16.4 ft (5 m) |
|---|---|
| Streaming range | 60 m (200′) |
