General |
|
| Dimensions without sun cover (HxWxD) | 4.1" x 5.5" x 2.0" (10.5 x 14.0 x 5.1 cm) |
| Dimensions with sun cover (HxWxD) | 4.3" x 5.8" x 2.2" (10.9 x 14.8 x 5.6 cm) |
| Weight without sun cover | 11.6 oz. (328 g) |
| Weight with sun cover | 13.2 oz. (375 g) |
| Temperature range | from 5° to 131° F (from -15° to 55° C) |
| Compass-safe distance | 7.9" (20 cm) |
| Case material | Fully-gasketed polycarbonate |
| Lens material | Glass with anti-glare and anti-fingerprint finish |
| Water rating | IPX7 |
| Brightness | 1200 cd/m2 (NIT) |
| Power usage | 5.9 W max |
| NMEA 2000® input voltage | 9 to 16 Vdc |
| NMEA 2000 LEN @ 9 Vdc | 13 (650 mA) |
