General |
|
| Dimension | 3.9" x 3.1" x 3.8" (100.3 x 79.4 x 97.1 mm) |
|---|---|
| Weight |
14.7 oz (418.0 g) |
|
Water rating |
IPX7 |
| Display Type | sunlight-visible, transflective memory-in-pixel (MIP) |
| Display Size | 1.00"W x 0.42"H (2.5 x 1.1 cm); 2.0" diag (5.0 cm) |
| Display resolution | 160 x 68 pixels |
|
Battery Type |
2 lithium AAA (not included) |
| Battery life |
up to 1 year |
| Operating range | -20° C (-4° F) to 60° C (140° F) with two AAA lithium batteries |
| Laser classification | Class 1 |
Scope Features |
|
| Colored pins | 1 color (red) |
|---|---|
| Pin diameter | .007” and larger |
| Ranging distance | 100 yards to game; 300 yards to reflective targets |
| Glass lens coating | target side is anti-reflective, water repellant and easy clean archer side is 20% reflective, water repellant and easy clean |
| Light projection | no visible light is ever projected toward the target |
| Pin brightness | ambient light sensor controlled or manual |
| Silent h3 trigger | |
| Shot counter | |
| Customizable fixed pins | |
| Angle compensated distance | |
| Auto brightness |
